12G SDI=HDMI 2.0 4K Switcher

1.12G HD video SDI/HDMI bidirectional converter , 4K level signal conversion equipment based on broadcast 12G SDI signal. The device input supports up to 12G SDI signals, and is compatible with 6G SDI signals and single-link signals below 3G. The product supports SDI to HDMI and HDMI to SDI function converters. Support audio de-embedding function, can output audio through 3.5mm headphone jack. The highest resolution supports the 3840X2160P60 and is backward compatible; the dual power supply system provides DC12V and USB5V DC power.
2.The device is equipped with a Micro USB interface. Users can obtain status or upgrade software through the USB interface. The Micro usb interface is also used for power supply of the device. It can be applied to USB mobile device power supply systems such as power bank. In addition, the equipment is equipped with 1/4 hot shoe screw hole, which is convenient for professional users to fix equipment.
