1) 2 screens splicing in 1 processor:4 DVI output ports are divided into 2 groups for horizontal splicing, vertical splicing, sa me size splicing,and different size splicing. A single unit up -loads 4,600,000 pixels and accepts splicing for 2 screens.
2) 2 windows  output:on  non-splicing mode, each  output  support 4 layers with any size or position.
3) Multiple cascade:machines can be cascaded to realize ultra wide display
4) Built-in input matrix for seamless switching between 7 inputs
5)  Logo saving
6) lmage freezing
7) Preset saving & loading
8) Accurate control for brightness & high grey level
9)  Serial port for future developing
10) More input ports:DVlx2, HDMlx2, DP 1.1 xl, 2 extended 2K lnputs(VGA, DVI or SDI, with loop function), or 1 extended 1.1 DP,HDM11.4
11) EDID management: customize input resolution for DP, DVI , HDMI and VGA.
12) Rotary output:splicing after rotary output.
13) Time task manager.
14) Preview switching
15）Customize output resolution
16）Computer host control2 Screens Splicing in 1 Processor

customize input/output resolution

With EDID management, LED-750H is able to customize the input resolution of DVI, HDMI and DP. For the output part, there are 18 available fixed resolutions and customize output resolution function. In order to adjust pixel-to-pixel display from different size LED walls, accurate resolution setting can also be done within this product.

Single Machine Supports 2 Screens Splicing

For horizontal/vertical, equal/unequal splicing.

2 independent outputs

LED-750H supports maximum 7 inputs. It canbe used as matrix of 7 inputs and 2 outputs. It can also control 2 different screen with independent content. Any input can be quickly switched to any output without the black or signal break-off.

Multiple cascade

Cooperates with video server, graphic card split the signal and outputs to multiple LED-750Hs, and cascade to achieve ultra wide splicing.

4 Layers Output

In the non-splicing mode, each port is able to display 4 independent layers. Input signal, size and position of them can be setup separately.

Preview Switching

When preview switch is on, DVI 1 output will work as the preview, and DVI 2 work as the program output. Save the preview to the user-defined preset(for switching convenience), and then press the TAKE key to realize seamless switching. The fade duration can be set. The picture shows how 3 layers and 1 layer switch with fade in and fade out.
